The Zinc Plated CONFAST Wedge Anchor can be installed in solid concrete in a dry or mildly corrosive condition, where moisture is at a minimum. They are available in diameters from 1/4-inch to 1-1/4-inch; each diameter is manufactured in different lengths to accommodate varying thicknesses of material to be attached to the concrete.
Each box of Zinc Plated CONFAST Wedge Anchor is packaged with the correct number and size of nuts and washer. The bit diameter required for drilling the hole in the concrete is equal to the diameter of the Zinc Plated CONFAST Wedge Anchor being installed. When installing the Zinc Plated CONFAST Wedge Anchor, a minimum of three to four threads must be below the surface of either the material being fastened or the concrete.
