The True Cost of Bearing Lubrication

What are the issues with bearing lubricant? According to a major ball bearing company, 54 percent of bearing failures are lubrication-related. Original equipment manufacturers (OEMs) often overlook a simple solution that can have a positive, long-term impact on profitability for themselves and their customers: the elimination of bearing lubricant. Download now to learn more!

Mnet 172046 784x392 fw 0
The True Cost of Bearing Lubrication By Matt Mowry Product Manager The True CosT of Bearing LuBriCaTion | 1 Table of Contents introduction................................................................................................................................2 hidden Costs of Lubrication ....................................................................................................3 Ancillary components for OEMs .......................................................................................3 Other costs not required for self-lubricating bearings .......................................................4 self-Lubricating Plastic Bearings ............................................................................................4 Benefits of plastic bearings ...............................................................................................4 Application parameters not conducive for self-lubricating plastic bearings ......................6 field applications using high-Performance Plastic Bearings..............................................6 2 | The True CosT of Bearing LuBriCaTion Introduction Today, machine and equipment manufacturers are feeling more pressure than ever to reduce costs without sacrificing machine performance and this balancing act can be difficult to achieve. Original equipment manufacturers (OEMs) often overlook a simple solution that can have a posi- tive, long-term impact on profitability for themselves and their customers: the elimination of bear- ing lubricant. By eliminating lubrication systems where possible, OEMs can reduce production costs, while at the same time making their equipment more marketable and less expensive to op- erate for the end users. What are the issues with bearing lubricant? According to a major ball bearing company, 54 per- cent of bearing failures are lubrication-related (see Image 1). In a study by the Massachusetts In- stitute of Technology (MIT), it was estimated approximately $240 billion is lost annually (across US industries) due to downtime and repairs to manufacturing equipment damaged by poor lubri- cation.1 Improper bearing lubrication or re-lubrication accounts for up to 40 to 50 percent of ma- chine failures. By eliminating lubrication from machinery, OEMs can minimize the costs and risks associated with maintenance for the end user. At the same time, costs related to the proper dis- posal of oil can be eliminated and the initial expenditure for ancillary components and processes (grease lines, zerks, manifolds, etc) can be decreased. There is a lower cost, easier-to-maintain machine component that eliminates the total cost of bearing lubricants: high performance, dry running plastic bearings. Image 1: Types of lubricated-related bearing failures. Source: SKF, USA Inc. The True CosT of Bearing LuBriCaTion | 3 Hidden Costs of Lubrication Proper lubrication delivery is critical for the operation of ball bearings, and most require continued mainte- nance for re-lubrication. The re-lubrication process typically requires scheduled machine downtime, which increases maintenance costs and causes a loss of production time. In addition, re-lubrication mainte- nance practices often fall short. While some processes are automated, the majority of re-lubrication is performed manually using a grease gun. This seemingly simple task actually involves a number of critical steps to ensure proper lubrication delivery, including correct amount of lube, the right grease gun, proper cleaning, and careful storage and handling con- ditions, just to name a few. In addition, it is critical to use the same grease for the entire lifespan of a bearing. The Technical Training Division of Life Cycle Engineering conducted a study that found 80 percent of maintenance workers surveyed scored less than 50 percent when it came to the basic technical skills needed to perform their job;2 and “bearing lubrication” was noted first on their list of tasks. re-lubrication maintenance practices fall short due to:  Lubrication not being properly or consistently administered; Image 2: Proper lubrication is critical for the operation of ball bearings. There are also additional parts required to protect them from contaminants. According to McNally Institute, the leading cause of bearing failure is due to contamination of the lubrication by moisture and solid particles. If as little as 0.002 percent water gets mixed into the lubrication system, it increases the probability of failure by 48 percent. Just six percent water can 3  Lubrication points not being easily accessible;  Maintenance personnel not being properly trained; and  Using the incorrect or improper quantity of lubricant. i. ancillary components for oeMs Using lubricated bearings can increase manufacturing complexity and expenses. They often need to be fitted with grease zerks and manifolds, oil lines, and some- times oil reservoirs and pumps. Not only are there extra costs associated with purchasing these compo- nents, there are also manufacturing costs associated with the machining and assembly of the mating parts. ancillary components for lubricated bearings:  Grease fittings / zerks / oil lines / pumps  Wipers / scrapers / felt wicks / seals  Grease guns  Grease / oil / lubrication reduce the lifetime by 83 percent. Ball bearings require seals to keep oil in and unwanted water and liquids out, as well as wipers / scrapers to keep dust and debris out. Seals only last so long and do not perform well in dirty and dusty environments and can also increase friction in the application. In agricultural machinery and lawn mowers, where dust and debris are prevalent during operation, seals and wipers may require frequent replacement. extra costs for lubricated bearings*:  Gravity-fed oil reservoir/lines: $50 to $300  Zerks: $2 to $40 (for four bearings and machining)  Seals, wipers and felt wicks: $4 to $12 (per bearing)  Automated oil reservoir / line: $1500 or more  Oil / grease / lubrication disposal *Keep in mind; self-lubricating plastic bearings do not require any of these additional parts. 4 | The True CosT of Bearing LuBriCaTion ii. other costs not required for self-lubricating bearings a. Labor A major oil company studied the time required to manually lubricate a single grease point. The results showed manual lubrication takes an average of three minutes per point. The average machine has 20 grease points to maintain. This correlates to a total labor cost of $7,300 annually for maintaining 20 grease points on one machine, every day, seven days per week.4 Another source claims that the average plant employs 2,196 bearings and spends $60,000 in re-lubrication costs per year; of that $60,000, $57,000 is used for labor alone. b. Downtime Improper bearing lubrication or re- lubrication accounts for up to 40 to 50 percent of machine failures. When a bearing fails prematurely, a number of actions may need to be taken. Replacement of the bearings, shafting, and even motors and other parts can be very costly. If the machine needs to be taken off-line, Image 3: Comparison chart comparing ball bearings to self-lubricating plastic plain bearings. expenses can potentially skyrocket. In a six-sigma lean manufacturing guide5, it is estimated that the average cost for downtime is $500 per hour, and in some automotive and other high-volume production factories, downtime costs are considerably higher. In addition, unplanned downtime can cause a ripple effect that impacts a plant’s production schedule. c. Disposal costs According to Valin6, proper disposal of lubricants by a process management company can amount to approximately 20 percent of the cost of annual lubricant expenditures. This means if a plant spends $50,000 per year on lubricants, they will spend approximately $10,000 in disposal costs. In addition, the cost of the lubrication itself can impact overall expenditures, as it is normally petroleum-based and directly linked to the price of oil. Image 4: igus® lines of self-lubricating plastic bearings are made from high-performance polymers, which are corrosion-resistant and maintenance-free. The True CosT of Bearing LuBriCaTion | 5 Self-Lubricating Plastic Bearings Self-lubricating plastic bearings are made of high- performance polymers and, unlike rolling-element bearings, slide instead of roll. They consist of a base polymer, which is optimized with fiber reinforcement and solid lubricants. The fiber reinforcements increase load carrying capabilities and wear-resistance, and the solid lubricants are transferred from the bearing to the micro finish of the shaft in order to reduce friction. No external oil or grease is needed for their operation; self-lubricating bearings operate completely dry. They are an ideal solution for applications in labs and food- processing machinery that require clean, oil-free operation. Plastic bearings also perform well in dirty environments since there is no oil to attract dust and dirt, like the agricultural industry. They can be used on softer shafting, even anodized aluminum, which has excellent corrosion resistance and is usually less expensive and easier to machine than case-hardened material or stainless steel. Benefits of plastic bearings:  No maintenance  Oil free, dry-running  Corrosion-resistant  Cost less than ball bearings  Handle contamination well and often do not require seals or scrapers  Ideal for very short-stroke applications, unlike linear ball bearings self-lubricating bearings are ideal for:  Harsh, extreme environments – dirt, dust, agriculture, outdoor equipment  Sensitive, clean environments – biotech, lab machines, medical equipment  Wash-down applications – packaging, food processing  Weight-sensitive applications (aimed at reducing fuel consumption and / or lowering the inertia of moving parts) i. eliminate maintenance costs Using high-performance, self-lubricating plastic bearings can significantly reduce maintenance costs, as well as reduce unplanned downtime due to bearing failure. OEMs that use self-lubricating plastic bearings are able to deliver a maintenance-free system that increases their end customer’s production throughput and the overall marketability of their product. In the event that a self-lubricated bearing does need replacement, the replacement part (a small, inexpensive plastic sleeve) can be purchased for a fraction of the cost of an entire re-circulating ball bearing. ii. Lower production costs Plastic bearings do not require the machining and other processes required to install ball bearings. They are less expensive and do not require grease fittings, lines or pumps. Plastic bearings also can be used on less expensive shafting, such as aluminum or cold- rolled-steel. Some companies offer online calculators to predict bearing lifetime to ensure it is ideal for the application; this eliminates the need for testing and saves time and errors in material choice. iii. application parameters not conducive for self-lubricating plastic bearings  High loads with high speeds: These lead to exces- sive frictional heat buildup and wear.  Highly cantilevered loads: Since self-lubricating plastic bearings slide (unlike ball bearings that roll), linear applications with higher coefficients of friction may result in uneven movements for highly can- tilevered loads or drive forces.  Extremely precise applications: Plastic bearings have a higher running clearance than ball bearings, sometimes .001” to .002”, and therefore are not ideal for applications needing extreme precision.  Extreme temperatures: Plastic bearings are not recommended for applications with long-term temperatures exceeding 484 degrees Fahrenheit. 6 | The True CosT of Bearing LuBriCaTion Image 5: *Based on 3/4 inch closed linear bearing and assuming replacement is required once per year. Field Applications Using High- Performance Plastic Bearings agricultural A manufacturer of equipment specifically for the farming industry produces ‘The Pick Planter’, which creates individual planting row units using walking gauge wheels to deliver a consistent planting depth. Oil-impregnated bronze bearings with graphite plugs were used to facilitate this movement until they began causing severe problems. They were even requiring replacement two to three times a season. On the West coast, the bronze bearings were experiencing high wear and premature failure due to the very abrasive conditions caused by high levels of volcanic ash in the soil. On the East coast, the high salt content in the air caused corrosion and seizure. By replacing all 144 bronze bearings with iglide® self- lubricating plastic bearings from igus®, the pick arms’ lifespan was increased by 500 to 600 percent. The actual bearings cost 70 to 80 percent less than bronze bearings and were more reliable. Packaging One manufacturer specializes in vertical, form, fill and seal (v/f/f/s) packaging equipment for handling a wide range of products: from green beans to candy to deter- gent. The machines are capable of reaching up to 160 cycles per minute and withstanding loads up to 15 pounds, while operating at speeds of 750 feet per minute. The manufacturer had been using metal linear ball bearings. After the metal bearings scored the shafts and leaked grease on some of the machines, the com- pany decided to replace them with self-lubricating The True CosT of Bearing LuBriCaTion | 7 DryLin® R linear plain bearings. To date, the linear bushings have surpassed the 10-million cycle mark on some of the company’s packaging machines with little to no noticeable wear. Medical In the quest to improve the way prostate cancer is detected and treated, a team of researchers from the Worcester Polytechnic Institute (WPI) in Massachusetts have developed a specialized mag- netic resonance imaging (MRI) compatible piezoelectric actuated robot. To facilitate different types of motion, the robot uses a DryLin® linear guide system and iglide® plastic self- lubricating plain bearings. The linear guides facilitate translational motion of the positioning module, which provides gross positioning for the robot’s needle driver. The needle driver is a vital part of the system, as it enables the rotation and translational movement of the needle cannula: a flexible tube inserted into the patient’s body cavity for MRI-guided diagnosis and therapy. The needle driver has a needle guide sleeve, a collet locking mechanism and passive optical tracking fidu- cial frame. Two plastic plain bearings are used in the front and rear of the driver to constrain the needle guide. The bearings enable the robot’s motor to rotate the needle using the collet mechanism by way of a timing belt. This rotating needle would reduce tissue damage while enhance targeting accuracy. Another 10 plain bearings were used to create a revolute joint, also known as a “pin joint” or “hinge joint”, to provide single-axis rotation. The linear guides chosen are comprised of hard- anodized aluminum rails and carriages and high-performance plastic sliding elements, which do not interfere with the MRI procedure. The linear slides operate without messy lubrication, which is important in a sterile medical environment. They also feature a lower-profile for applications where installation space is an issue. The specific plastic plain bearings used were an ideal choice for the robot, as they are comprised of FDA- compliant polymers specifically designed for applica- tions with contact to food or drugs. About igus® igus® develops industry-leading products based on a belief in making functionally advanced, yet affordable plastic components and assemblies, including iglide® plastic plain bearings, igubal® spherical bearings, and DryLin® linear bearings and guide systems. No lubrica- tion, less maintenance, lower costs, longer life cycles – these key principles apply to all igus® products, sys- tems and services. Tried and tested in terms of durability, friction properties and stability, igus® plastics are the technological core of the company’s range. igus® inc. PO Box 14349, East Providence, RI 02914 1-888-803-1895 | sales@igus.com | www.igus.com igus, iglide, igubal, and DryLin are registered trademarks of igus Inc. All other company names and products are trademarks or registered trademarks of their respective companies. 1 http://www.azom.com/news.asp?newsID=11342 2 http://www.lce.com/pdf/trainingneeds.pdf 3 http://www.mcnallyinstitute.com/02-html/2-10.html 4 http://www.lubricationautomation.com/ez.php?Page=2087 5 http://www.plant-maintenance.com/articles/lean_maintenance_for_lean_manufacturing.pdf 6 http://www.valin.com/index.php/blog/15-filtration/117-cut-lubricant-costs-up-to-50
