OEO Energy Solutions
LED-8030
High-Bay
H i g h - B a y L E D R e t r o f i t L a m p
w w w . o e o . c o m
Replace your 400W Metal Halide
lamp with our 150W LED Retrofit,
and achieve 67% energy savings!
Keep your existing fixture in place
– simply wire past the ballast and
screw in the lamp.
All OEO LED Retrofits come with a
5 year warranty, 50,000 hour rated
life and will dramatically cut your
energy consumption, while provid-
ing a better, more consistent light.
Purchase the OEO 150W LED and
enjoy all of these savings and a
superior light quality!
FEATURES
67% energy savings
ROI in 18 months or better
Rebate eligible
Patented design
100% reduction in mercury
Simple installation
5 year warranty
Metal Halide LED
Rated Life 15,000 hours 50,000 hours
Annual Cost to Operate 24/7 $447.83 $144.46
Cost Comparison @ 50,000 hrs. $2,560.00 $826.00
Replacements Needed 5x
+ Maintenance, Labor & Lift -0-
TOTAL SAVINGS = $0 $1,734
The LED-8030 maintains constant, bright-light quality over its 50,000
hour lifespan. Traditional Metal Halide lamps experience diminishing
light quality over their short 15,000 hour life. During that same 50,000
hour LED lamp life, you would have to replace the Metal Halide bulb 5
times! Add to that maintenance, labor and lift costs and the benefits of
making the switch to LED are clear.
Energy Savings...Simplified.™
P R O D U C T S P E C I F I C A T I O N S
L E D 1 5 0 W H I G H B A Y
OEO Energy Solutions
143 East Main Street
Lake Zurich, IL 60047
1-800-553-2112
www.oeo.com
DIMENSIONS
6.02”
9.
34
”
8.41”
9.06”
2.
50
”
2.
90
”
3.
60
”
Installation Notes:
bypassed when present. LED retro-
-
liver best results. Installing surge/
lightning protectors is highly rec-
ommended and helps to eliminate
premature driver failure caused by
• Provides brighter, more consistent light for a brighter, safer environment.
•
• Perfect for factories, warehouses, and large industrial spaces.
• Design features uplighting to eliminate shadows on ceiling, and both down and side-mounted
LEDs, delivering a wide, uniform light distribution – 360° illumination.
• Passive and active cooling with internal Delta brand brushless fan keeps lamp cool and allows
•
screw in lamp.
•
• Future servicing can be done without an electrician!
• UL damp location rated.
• Aluminum/Polycarbonate body - double insulated.
Replaces Wattage Lumens Rated Life Base
Input
Voltage CCT CRI
Power
Factor
400W MH
or HPS 150W
10000
11000
12000
50,000
Hours
(L70)
E39
Standard
Base
120-277
3000K
4200K
5700K
>80 >99
