InnovaMass iSeries
240i
INLINE
241i
INSERTION
with Probe Retractor
(easily adjusts
up and down
with standard drill)
5 Harris Court, Building L, Monterey, CA 93940, USA / 800.866.0200 / 831.373.0200 / fax 831.373.4402 / sierrainstruments.com
InnovaMass. Reinvented.
In 1997, Sierra was the first to introduce a combination volumetric vortex and multi-
variable mass flow meter. Today, Sierra’s completely redesigned InnovaMass®
iSeries™ 240i/241i builds on two decades of success measuring five process variables
for gas, liquid and steam with one connection.
Now, with the latest hyper-fast microprocessors, robust software applications, field
diagnostic and adjustment capability, and a new state-of-the-art flow calibration
facility, Sierra’s vortex iSeries delivers precision, performance, and application
flexibility never before possible.
It has Apps!
Experience innovative flow energy management tools driven by our new Raptor II OS
that will empower your process and save you time and money
● FloPro™ vastly improves low flow measurement calculation
● Dial-A-Pipe™ allows you to quickly change pipe sizes in the field
● Dial-A-Fluid™ measures a variety of fluids whenever you choose
● qMix™ makes/measures custom gas mixtures
â—Ź Many more apps to come
Field Independence
With Sierra’s advanced Smart Interface Portal (SIP),
tap into your InnovaMass and bring up a variety of
powerful software interfaces to enhance your
meter’s performance.
● Meter Tuning™ cancels environmental noise,
greatly improving accuracy
● ValidCal™ Diagnostics closely monitors meter
performance and validates output
â—Ź Make fast firmware upgrades in the field
â—Ź Expect a mobile app for your cell phone in 2016
World-Class Flow Calibration Facility
Every flow meter is only as good as its calibration. Each InnovaMass is calibrated by
Sierra’s new calibration facility in Monterey, California, to assure the best possible
performance. Flow standards with accuracies better than 0.2% of reading are used to
assure the highest accuracy possible.
Next Day Shipping
Go to Sierra’s online store to custom configure and buy InnovaMass. We stock select
models for next day shipment. Sierra is the only company in the industry where you
can buy vortex meters factory direct. Visit sierrainstruments.com/shop
Learn More
See the back of this data sheet for technical details or visit sierrainstruments.com
for more information on the Innovamass iSeries.
(InnovaMass specs on back)
Application Tech Notes
Burner Control for Manufacturing
Industrial Mass Flow Control of Fuel-to-Air Ratio
Industrial mass fl ow control is a crucial part of burner and combustion control in
manufacturing applications. Precise mass fl ow control of the fuel-to-air ratio to the burner
keeps melt temperatures constant which produces quality products for the manufacturing
industry including glass, metals, and ceramics manufacturing. To create the optimal fl ame
temperature, one mass fl ow controller is used to control the gas feed and another mass fl ow
controller controls the exact combustion air supply required (See Figure 1).
Glass manufacturing
process engineers,
for example, are
always seeking
methods to improve
glass quality,
reduce raw material
waste, and increase
production capacity.
They require a
constant burner
temperature at all
times to produce the
perfect quality glass.
If too much natural
gas is fed into the
burner, the fl ame
will be too hot and
the glass will melt.
If there is not enough natural gas, the fl ame will not melt the glass resulting in a defective
product. Without mass fl ow controllers, manual control of the air and natural gas fl ow to
the burners results in unacceptable levels of rejected materials, as well as excessive gas
consumption.
To automate the burner control process, Sierra’s SmartTrak® 100 (See Figure 2) o ers the
perfect solution with over 100,000 MFCs installed over the last 20 years. SmartTrak mass fl ow
controllers use thermal technology for direct mass fl ow control of the fuel-to-air ratio to the
burner.
Only through thermal mass fl ow technology, not volumetric, the SmartTrak fl ow controller
counts and controls every gas molecule fl owing through the instrument to achieve
unmatched precision. The SmartTrak 100 MFC delivers smooth, stable, accurate, and re-
peatable gas mass fl ow control you can rely on, every time. Una ected by upstream gas
temperature and pressure fl uctuations, gas mass fl ow control is direct and unequivocal.
Only with this type of precision control, can manufacturers control the exact fuel-to-air ratio
for combustion which results in superior product quality, increased e ciency, and ultimately
more profi t to the bottom line. Learn More at www.sierrainstruments.com/library/videos/
capillary-thermal-mass-fl ow-meter-technology
The SmartTrak is CE approved, available in any fl ow range you specify from low fl ows (0 to
0.1 sccm) to high fl ows (to 1000 slpm) including a small footprint at 50 slpm (ideal for OEMs)
and full suite of digital communicati n for easy process integration. SmartTrak also o ers a
wide p rating r nge f r temperature and pressure with high pressure options (up to 5000
psig) and low pressure drop (4.5 psid). Specifi cally designed for industrial mass fl ow control
combustion applications, the MaxTrak 180, is available with 316 stainless-steel fl anges for the
heaviest industrial environments with industrial waterproof NEMA 6 and IP67 enclosures.
Learn More at www.sierrainstruments.com/scientifi c-industrial
Figure 2: SmartTrak® 100 Digital Mass Flow
Controller
• Direct mass fl ow +/- 0.5% full scale
accuracy
• Mass fl ow rates up to 1000 slpm and
down to 0 to 0.1 sccm
• Pressure to 5000 psig (345 barg) with
low pressure drop ( 4.5 psid)
• Small footprint at 50 slpm ideal for
OEMs
• Industrial mass fl ow controller option
with 316 stainless-steel fl anges and
waterproof NEMA 6 and IP67 enclosures
• True multi-gas
• View and change every aspect of the
instrument with user-friendly push button
display or remote Pilot Module
• Plug in Compod™ to make MFC a mini
PLC with Modbus RTU
• Profi bus DP and Foundation Fieldbus
digital communications
• 10-point NIST calibration on primary
standards or “Do-it-Yourself” calibration
program
• Fast one-day delivery online
Figure 1: Burner Control Application
Burner Control for Manufacturing: Industrial Mass Flow Control of Fuel-to-Air Ratio
