MTLT305D Dynamic Tilt Sensor Module

The new MEMS based, MTLT305D Dynamic Tilt Sensor Module combines accelerometers, gyroscopes and a temperature sensor with advanced calibration and correction algorithms to provide accurate 3D acceleration, 3D rate and Pitch and Roll measurement in dynamic, moving vehicle applications.

The MTLT305D uses advanced sensor fusion (Extended Kalman Filtering) and calibration algorithms to achieve 0.5 degree tilt and 50k hours and is ITAR- Free

It includes CAN J1939 and RS232 interfaces for network connectivity. The miniature plastic housing is durable under hazardous environments (IP68 and IP69K ratings). It includes an Ampseal 16, 6 position connector and supports a wide 4.9 V to 32 V supply input range (qualified for use in both 12 V and 24 V vehicle platforms).

“This new Dynamic Tilt Sensor Module provides the best performance for the price in the industry,” says Mike Horton, CTO of ACEINNA. “Not only is the MTLT extremely compact compared to competing modules, it is extremely rugged, well qualified and inexpensive.”

Easy to integrate, the MTLT305D supports industry standard SAE J1939 messaging over the CAN bus, and the included ACEINNA NAV-VIEW software provides a simple to use graphical interface to display, record, playback, and analyze all the MTLT305D parameters over the RS232 port. NAV-VIEW can also be used to set a wide range of user-configurable fields in the MTLT305D to optimize the system performance for various dynamic applications.
