Micro Drill Analyzing Scope

Ideal for inspecting the quality of drills used in micro-manufacturing and micro-electronics, this microscope provides a single-purpose, low-cost alternative to optical comparators and toolmakers microscopes.

title
title

[[{"fid":"161092","view_mode":"media_original","type":"media","attributes":{"height":232,"width":320,"style":"float: right; margin-left: 5px; margin-right: 5px; border: 1px solid black;","alt":"Micro Drill Analyzing Scope","title":"Micro Drill Analyzing Scope","class":"media-element file-media-original"}}]]A new $495.00 Micro Drill Analyzing Microscope from Titan Tool Supply, Inc. (Buffalo, NY) inspects the geometry, finish, and accuracy of new and re-sharpened miniature carbide drills as small as 1/8” diameter. Ideal for inspecting the quality of drills used in micro-manufacturing and micro-electronics, it provides a single-purpose, low-cost alternative to optical comparators and toolmakers microscopes, which entail a significant amount of set-up time, according to the company. Titan Tool’s Model MDGA features a 30X magnification lens with a special reticle, two-position viewing, and 360-degree rotation of the drill in a precision collets holder to allow for complete inspection without refocusing or other adjustments. A travel rack and pinion brings the drill into focus.

See more at www.TitanToolSupply.com.
